ASTM A213 SS 904L Boiler Tubes Manufacturer, Supplier

Prism TuboTech Pvt. Ltd. is India's Most Distinguished and pre-eminent stainless steel company which is dealing with manufacturing of value added high end stainless steel products in India.

Table Of Content

About Stainless Steel 904L Boiler Tubes
Stainless Steel 904L Boiler Tubes Specification
Stainless Steel 904L Boiler Tubes Equivalent Grades
Types of Stainless Steel 904L Boiler Tubes
Chemical Composition of Stainless Steel 904L Boiler Tubes
Stainless Steel 904L Boiler Tubes Mechanical Properties
Other Types of Stainless Steel 904L Boiler Tubes
People Also Search for SS 904L Boiler Tubes

Prism TuboTech Pvt Ltd manufactures high-quality Stainless steel 904L Boiler tubes. Our organization has several quality checks along with testing which our products go through. This is done to make sure that the quality is up to the industry standard.

Austenitic Stainless Steel 904L Boiler Tubes, Stainless Steel 904L Boiler Tubing, Stainless Steel 904L Boiler Tubes, UNS N08904 Boiler Tubes, Stainless Steel 1.4539 Boiler Tubes, UNS N08904 Boiler Tube, Stainless Steel 904L Boiler Tubes Manufacturer, 904L Stainless Steel Boiler Tube, Stainless Steel 904L Boiler Tubes Supplier, Stainless Steel N08904 Boiler Tubes Exporter, SS 904L Boiler Tubes, ASTM A213 Stainless Steel 904L Boiler Tubes Supplier in India.

Our organization has stringent rules for the production of products that comply with regulatory requirements linked to the environment, health and safety, and pollution prevention. These boiler tubes are produced in many dimensions and specifications, as needed by the client or buyer.

Stainless Steel TP904L Boiler Tubes, 904L Stainless Steel High Pressure Boiler Tubes, ASME SA213 Stainless Steel 904L Boiler Tubing, SS 904L Medium Pressure Boiler Tube, Stainless Steel 1.4539 Boiler Tubes Stockist, Stainless Steel 1.4539 Boiler Tubes Manufacturer, 904L Stainless Steel Boiler Tubes Price, SS 904L Boiler Tube Manufacturer, Jindal Stainless Steel 904L Boiler Tubes, SS 904L Boiler Tube, SS 904L Boiler Tube Supplier, Stainless Steel TP904L Seamless Boiler Tubes Stockholder, Stainless Steel 904L Boiler Tubes Exporter in Mumbai, India.

Stainless steel 904L Boiler tube is one of the super-austenitic stainless steel metals, that has a lower carbon content. It has high corrosion resistance in a wide range of environments. It has high chromium and nickel, along with molybdenum mixed into the composition.

Due to this, it has excellent resistance to pitting and crevice corrosion caused by chloride and reducing acids. It has remarkable resistance to various concentrations of sulphuric acid. The alloy can be welded and processed easily using standard fabrication methods. Stainless steel 904L Boiler tube has seen applications where resistance to chlorides and acids is necessary and top priority. These include air pollution control, chemical processing, metallurgical processing, oil and gas production, pharmaceutical industry, and seawater and saline waters.

Grade

904L

At 35°C, Stainless steel 904L Boiler tube can withstand an environment that contains sulphuric acids up to 100% concentration.

Along with this it also has great resistance to numerous inorganic and organic acids. Even though it has good resistance to many acids, acids containing halide ions can be aggressive, making the alloy ineffective against those kinds of acids. The temperature of the hot forming processes should be between 850–1150°C for welding and forming, followed by quenching. Cold forming techniques can be used, due to SS 904L's ductility and formability. It needs more powerful processing equipment when compared to SS 304 grade. Alloy 904L's cold work hardening rate makes it less machinable than stainless steel 410 and 304.

Stainless Steel 904L Boiler Tubes Specification

Specifications

ASTM A213 / ASME SA213

Outside Diameter

Upto 355.60 mm (Expander pipe in 406.4/ 457.0/ 508.0 mm)

Thickness

Upto 40.00 mm

Length

Upto 14 mtr (max tube length can be met upto 21 mtr.)

Deburring Angle

30°+ 5 and 37°± 2.5

Tubes End Types

Plain End / Beveled End

ASME SA 213 Equivalent Grades of Stainless Steel 904L Boiler Tubes

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	KS	AFNOR	EN
SS 904L	1.4539	N08904	SUS 904L	904S13	STS 317J5L	Z2 NCDU 25-20	X1NiCrMoCu25-20-5

Types Of Stainless Steel 904L Boiler Tubes

904L Stainless Steel Boiler Tube Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Cu
SS 904L	0.020 max	2.00 max	1.00 max	0.040 max	0.030 max	19.00 – 23.00	4.00 – 5.00 max	23.00 – 28.00	1.00 – 2.00

904L Stainless Steel Boiler Tubing Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
7.95 g/cm3	1350 °C (2460 °F)	Psi – 71000 , MPa – 490	Psi – 32000 , MPa – 220	35 %

Stainless Steel 904L Boiler Tube Used In Most Types Of Boilers

Waste heat boilers
Concentrated solar power (CSP) boilers
Black liquor recovery boilers
Biomass-fired boilers
Coal-fired power boilers
Syngas coolers
Reheaters
Advanced ultra supercritical (AUSC) boilers
Superheaters

904L Stainless Steel Fire Tube Boiler Sizes

OUTER DIAMETER (OD)	10.2 – 139.7 mm (from 26.9 mm manufactured as hot rolled)
WALL THICKNESS (WT)	0.5 – 16.0 mm (from 2.6 mm manufactured as hot rolled)

904L Stainless Steel Boiler Tube Pressure Rating

AVE. WALL INCHES	MIN YIELD STRENGTH (PSI)	MIN TENSILE STRENGTH (PSI)	THEORETICAL BURST PRESSURE * (PSI)	WORKING PRESSURE (PSI) 25% OF BURST	THEORETICAL YIELD POINT ** (PSI)	COLLAPSE PRESSURE *** (PSI)
0.250	0.020	30,000	75,000	14,286	3,571	5,714	4,416
0.250	0.028	30,000	75,000	21,649	5,412	8,660	5,967
0.250	0.035	30,000	75,000	29,167	7,292	11,667	7,224
0.250	0.049	30,000	75,000	48,355	12,089	19,342	9,455
0.250	0.065	30,000	75,000	81,250	20,313	32,500	11,544
0.375	0.020	30,000	75,000	8,955	2,239	3,582	3,029
0.375	0.028	30,000	75,000	13,166	3,292	5,266	4,145
0.375	0.035	30,000	75,000	17,213	4,303	6,885	5,077
0.375	0.049	30,000	75,000	26,534	6,634	10,614	6,816
0.375	0.065	30,000	75,000	39,796	9,949	15,918	8,597
0.500	0.020	30,000	75,000	6,522	1,630	2,609	2,321
0.500	0.028	30,000	75,000	9,459	2,365	3,784	3,172
0.500	0.035	30,000	75,000	12,209	3,052	4,884	3,906
0.500	0.049	30,000	75,000	18,284	4,571	7,313	5,304
0.500	0.065	30,000	75,000	26,351	6,588	10,541	6,786
0.500	0.083	30,000	75,000	37,275	9,319	14,910	8,307
0.625	0.020	30,000	75,000	5,128	1,282	2,051	1,859
0.625	0.028	30,000	75,000	7,381	1,845	2,953	2,568
0.625	0.035	30,000	75,000	9,459	2,365	3,784	3,172
0.625	0.049	30,000	75,000	13,947	3,487	5,579	4,335
0.625	0.065	30,000	75,000	19,697	4,924	7,879	5,591
0.625	0.083	30,000	75,000	27,124	6,781	10,850	6,910
0.625	0.095	30,000	75,000	32,759	8,190	13,103	7,734
0.625	0.109	30,000	75,000	40,172	10,043	16,069	8,639
0.750	0.028	30,000	75,000	6,052	1,513	2,421	2,156
0.750	0.035	30,000	75,000	7,721	1,930	3,088	2,669
0.750	0.049	30,000	75,000	11,273	2,818	4,509	3,664
0.750	0.065	30,000	75,000	15,726	3,931	6,290	4,749
0.750	0.083	30,000	75,000	21,318	5,330	8,527	5,905
0.750	0.095	30,000	75,000	25,446	6,362	10,179	6,637
0.750	0.109	30,000	75,000	30,733	7,683	12,293	7,453
0.750	0.120	30,000	75,000	35,294	8,824	14,118	8,064
0.875	0.020	30,000	75,000	3,593	898	1,437	1,340
0.875	0.028	30,000	75,000	5,128	1,282	2,051	1,859
0.875	0.035	30,000	75,000	6,522	1,630	2,609	2,304
0.049	30,000	75,000	9,459	2,365	3,784	3,172
0.875	0.065	30,000	75,000	13,087	3,272	5,235	4,126
0.875	0.083	30,000	75,000	17,560	4,390	7,024	5,152
0.875	0.095	30,000	75,000	20,803	5,201	8,321	5,807
0.875	0.109	30,000	75,000	24,886	6,221	9,954	6,543
0.875	0.120	30,000	75,000	28,346	7,087	11,339	7,100
1.000	0.028	30,000	75,000	4,449	1,112	1,780	1,633
1.000	0.035	30,000	75,000	5,645	1,411	2,258	2,027
1.000	0.049	30,000	75,000	8,149	2,037	3,259	2,796
1.000	0.065	30,000	75,000	11,207	2,802	4,483	3,647
1.000	0.083	30,000	75,000	14,928	3,732	5,971	4,567
1.000	0.095	30,000	75,000	17,593	4,398	7,037	5,159
1.000	0.109	30,000	75,000	20,908	5,227	8,363	5,827
1.000	0.120	30,000	75,000	23,684	5,921	9,474	6,336
1.000	0.134	30,000	75,000	27,459	6,865	10,984	6,963
1.250	0.035	30,000	75,000	4,449	1,112	1,780	1,633
1.250	0.049	30,000	75,000	6,380	1,595	2,552	2,260

904L Stainless Steel Water Tubing Boiler Tolerances

OD Tolerance: +0.005/-0 in.
Hardness: Maximum 80 HRB (Rockwell)
Wall Thickness: ±10%
Chemistry: Min. 2.5% Molybdenum
