ASTM A213 SS 316 Boiler Tubes Manufacturer, Supplier

Prism TuboTech Pvt. Ltd. is India's Most Distinguished and pre-eminent stainless steel company which is dealing with manufacturing of value added high end stainless steel products in India.

Table Of Content

About Stainless Steel 316 Boiler Tubes
Stainless Steel 316L Boiler Tubes Specification
Stainless Steel 316H Boiler Tubes Equivalent Grades
Types of Stainless Steel 316 Boiler Tubes
Chemical Composition of Stainless Steel 316L Boiler Tubes
Stainless Steel 316H Boiler Tubes Mechanical Properties
Other Types of Stainless Steel 316 Boiler Tubes
People Also Search for SS 316L Boiler Tubes

Prism TuboTech Pvt. Ltd. is one of the prominent manufacturers of Stainless steel 316 Boiler Tubes in India. These tubes have to go through several quality examinations to assure the best quality items.

Stainless Steel 316 Boiler Tubes, Stainless Steel 316 Boiler Tubing, 316 Stainless Steel Boiler Tube, UNS S31603 Boiler Tubes, Stainless Steel S31600 Boiler Tubes Exporter, Stainless Steel 316L Boiler Tubes, Stainless Steel 316H Boiler Tubes Manufacturer, Stainless Steel 1.4435 Boiler Tubes, Stainless Steel 316H Boiler Tubes, ASTM A213 Stainless Steel 316 Boiler Tubes Supplier in India.

Our professionals have extensive knowledge about the industry, due to which we have achieved success in this sector. We supply great quality SS products in a range of sizes and forms at competitive prices.

Stainless Steel TP316L Boiler Tubes, 316 Stainless Steel Boiler Tubes Price, SS 316 Boiler Tubes, Jindal Stainless Steel 316L Boiler Tubes, Stainless Steel 1.4401 Boiler Tubes, Stainless Steel 1.4404 Boiler Tubes Manufacturer, Stainless Steel TP316H Seamless Boiler Tubes Stockholder, SS 316 Boiler Tube, SS 316 Medium Pressure Boiler Tube, SS 316 Boiler Tube Supplier, Stainless Steel 316H Boiler Tubes Exporter in Mumbai, India.

Stainless steel 316L Boiler Tubes are the second most utilized stainless steel grade after grade 304. It is also a type of austenitic grade of steel, giving it excellent toughness at a wide range of temperatures, including cryogenic temperatures. The alloy is a chromium and nickel composition with the addition of molybdenum. The molybdenum gives the alloy better corrosion resistance than SS 304, specifically greater pitting and crevice corrosion resistance in chloride conditions.

Stainless steel 316 Boiler Tubes have 2 variations, SS 316L and SS 316H grade. The naming convention is based upon the carbon content each of the grades has. Stainless steel 316L has lower carbon content, which is limited to 0.03 percent. On the other hand, 316H has a carbon content between 0.04% to 0.1%, along with the omission of nitrogen from the composition. SS 316 can be used in intermittent service to 870°C and continuous service to 925°C.

Grade

316

If water corrosion resistance is an important factor, then these tubes shouldn't be used at temperatures between 425-860°C.

Stainless steel 316L Boiler Tubes high resistance to grain boundary carbide precipitation than 316 grade. It is recommended to use in heavy gauge welded components. It also has a higher resistance to intergranular corrosion. There is usually very less difference between 316 and 316L in terms of corrosion resistance. Stainless steel 316H Boiler Tubes help it to be used at elevated temperatures due to their greater tensile and yield strength. Because of Grade 316H's greater strength at higher temperatures, it is occasionally utilized in structural and pressure-containing applications at temperatures exceeding 500°C.

SS 316L Boiler Tubes, Stainless Steel 316L Boiler Tubes Supplier, Austenitic Stainless Steel 316 Boiler Tubes, UNS S31609 Boiler Tube, SS 316H Boiler Tubes,316L Stainless Steel High Pressure Boiler Tubes, Stainless Steel 1.4436 Boiler Tubes Stockist, ASME SA213 Stainless Steel 316L Boiler Tubing, SS 316 Boiler Tube Manufacturer

Stainless Steel 316 Boiler Tubes Specification

Specifications

ASTM A213 / ASME SA213

Outside Diameter

Upto 355.60 mm (Expander pipe in 406.4/ 457.0/ 508.0 mm)

Thickness

Upto 40.00 mm

Length

Upto 14 mtr (max tube length can be met upto 21 mtr.)

Deburring Angle

30°+ 5 and 37°± 2.5

Tubes End Types

Plain End / Beveled End

ASME SA 213 Equivalent Grades of Stainless Steel 316L Boiler Tubes

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 316	1.4401 / 1.4436	S31600	SUS 316	316S31 / 316S33	–	Z7CND17‐11‐02	X5CrNiMo17-12-2 / X3CrNiMo17-13-3
SS 316L	1.4404 / 1.4435	S31603	SUS 316L	316S11 / 316S13	03Ch17N14M3 / 03Ch17N14M2	Z3CND17‐11‐02 / Z3CND18‐14‐03	X2CrNiMo17-12-2 / X2CrNiMo18-14-3
SS 316H	1.4401	S31609	–	–	–	–	–

Types Of Stainless Steel 316H Boiler Tubes

316 Stainless Steel Boiler Tube Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Fe
SS 316	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 – 18.00	2.00 – 3.00	11.00 – 14.00	67.845 min
SS 316L	0.035 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 – 18.00	2.00 – 3.00	10.00 – 14.00	68.89 min
SS 316H	0.10 max	2.0 max	0.75 max	0.045 max	0.030 max	16.00 – 18.00	2.00 – 3.00	10.00 – 14.00	68.89 min

316 Stainless Steel Boiler Tubing Mechanical Properties

Grade	Density	Melting Point	Tensilee Strength	Yield Strength (0.2%Offset)	Elongation
SS 316	8.0 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %
SS 316L	8.0 g/cm3	1399 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %
SS 316H	8.0 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

Stainless Steel 316H Boiler Tube Used In Most Types Of Boilers

Waste heat boilers
Concentrated solar power (CSP) boilers
Black liquor recovery boilers
Biomass-fired boilers
Coal-fired power boilers
Syngas coolers
Reheaters
Advanced ultra supercritical (AUSC) boilers
Superheaters

316 Stainless Steel Fire Tube Boiler Sizes

OUTER DIAMETER (OD)	10.2 – 139.7 mm (from 26.9 mm manufactured as hot rolled)
WALL THICKNESS (WT)	0.5 – 16.0 mm (from 2.6 mm manufactured as hot rolled)

316L Stainless Steel Boiler Tube Pressure Rating

AVE. WALL INCHES	MIN YIELD STRENGTH (PSI)	MIN TENSILE STRENGTH (PSI)	THEORETICAL BURST PRESSURE * (PSI)	WORKING PRESSURE (PSI) 25% OF BURST	THEORETICAL YIELD POINT ** (PSI)	COLLAPSE PRESSURE *** (PSI)
0.250	0.020	30,000	75,000	14,286	3,571	5,714	4,416
0.250	0.028	30,000	75,000	21,649	5,412	8,660	5,967
0.250	0.035	30,000	75,000	29,167	7,292	11,667	7,224
0.250	0.049	30,000	75,000	48,355	12,089	19,342	9,455
0.250	0.065	30,000	75,000	81,250	20,313	32,500	11,544
0.375	0.020	30,000	75,000	8,955	2,239	3,582	3,029
0.375	0.028	30,000	75,000	13,166	3,292	5,266	4,145
0.375	0.035	30,000	75,000	17,213	4,303	6,885	5,077
0.375	0.049	30,000	75,000	26,534	6,634	10,614	6,816
0.375	0.065	30,000	75,000	39,796	9,949	15,918	8,597
0.500	0.020	30,000	75,000	6,522	1,630	2,609	2,304
0.500	0.028	30,000	75,000	9,459	2,365	3,784	3,172
0.500	0.035	30,000	75,000	12,209	3,052	4,884	3,906
0.500	0.049	30,000	75,000	18,284	4,571	7,313	5,304
0.500	0.065	30,000	75,000	26,351	6,588	10,541	6,786
0.500	0.083	30,000	75,000	37,275	9,319	14,910	8,307
0.625	0.020	30,000	75,000	5,128	1,282	2,051	1,859
0.625	0.028	30,000	75,000	7,381	1,845	2,953	2,568
0.625	0.035	30,000	75,000	9,459	2,365	3,784	3,172
0.625	0.049	30,000	75,000	13,947	3,487	5,579	4,335
0.625	0.065	30,000	75,000	19,697	4,924	7,879	5,591
0.625	0.083	30,000	75,000	27,124	6,781	10,850	6,910
0.625	0.095	30,000	75,000	32,759	8,190	13,103	7,734
0.625	0.109	30,000	75,000	40,172	10,043	16,069	8,639
0.750	0.028	30,000	75,000	6,052	1,513	2,421	2,156
0.750	0.035	30,000	75,000	7,721	1,930	3,088	2,669
0.750	0.049	30,000	75,000	11,273	2,818	4,509	3,664
0.750	0.065	30,000	75,000	15,726	3,931	6,290	4,749
0.750	0.083	30,000	75,000	21,318	5,330	8,527	5,905
0.750	0.095	30,000	75,000	25,446	6,362	10,179	6,637
0.750	0.109	30,000	75,000	30,733	7,683	12,293	7,453
0.750	0.120	30,000	75,000	35,294	8,824	14,118	8,064
0.875	0.020	30,000	75,000	3,593	898	1,437	1,340
0.875	0.028	30,000	75,000	5,128	1,282	2,051	1,859
0.875	0.035	30,000	75,000	6,522	1,630	2,609	2,304
0.049	30,000	75,000	9,459	2,365	3,784	3,172
0.875	0.065	30,000	75,000	13,087	3,272	5,235	4,126
0.875	0.083	30,000	75,000	17,560	4,390	7,024	5,152
0.875	0.095	30,000	75,000	20,803	5,201	8,321	5,807
0.875	0.109	30,000	75,000	24,886	6,221	9,954	6,543
0.875	0.120	30,000	75,000	28,346	7,087	11,339	7,100
1.000	0.028	30,000	75,000	4,449	1,112	1,780	1,633
1.000	0.035	30,000	75,000	5,645	1,411	2,258	2,027
1.000	0.049	30,000	75,000	8,149	2,037	3,259	2,796
1.000	0.065	30,000	75,000	11,207	2,802	4,483	3,647
1.000	0.083	30,000	75,000	14,928	3,732	5,971	4,567
1.000	0.095	30,000	75,000	17,593	4,398	7,037	5,159
1.000	0.109	30,000	75,000	20,908	5,227	8,363	5,827
1.000	0.120	30,000	75,000	23,684	5,921	9,474	6,336
1.000	0.134	30,000	75,000	27,459	6,865	10,984	6,963
1.250	0.035	30,000	75,000	4,449	1,112	1,780	1,633
1.250	0.049	30,000	75,000	6,380	1,595	2,552	2,260

316 Stainless Steel Water Tubing Boiler Tolerances

OD Tolerance: +0.005/-0 in.
Hardness: Maximum 80 HRB (Rockwell)
Wall Thickness: ±10%
Chemistry: Min. 2.5% Molybdenum

Other Types Of Stainless Steel 316H Boiler Tubes

316 Stainless Steel 316H Fire-Tube Boiler Tubes
316 Stainless Steel Heat Expansion Boiler Tube
SS 316 Boiler Tube Price Per Meter
SS 316 Surface Bright Boiler Tubes
ASME SA213 SS 316 Seamless Boiler Tubes
Cold drawn Stainless Steel 316 Boiler Tubes
ASME SA213 SS 316 Cold-Finished Boiler Tubes
Stainless Steel 316 High Pressure Boiler Tube
SS 316 High Pressure Boiler Tubing Exporter in India
Weight of 316 Stainless Steel Boiler Tube
316 Stainless Steel IBR Seamless Boiler Tubes
ASTM A213 SS 316 Jindal Boiler Tubes
Jindal Stainless Steel 316 Boiler Tube Price List
SS 316 Boiler Tube Size Chart in mm
Stainless Steel 316L High-Temperature Boiler Tube Manufacturer
316 Stainless Steel Boiler Tube Pressure Rating Chart
Stainless Steel 316 Cold Rolled Boiler Tube
SS 1.4435 Water Tube Boiler Tubing
Hot Rolled SS 316 Boiler Tube Stockists in India
316 Stainless Steel Boiler Tube Weight Chart
Stainless Steel 316 Water-Tube Boiler Tubes Supplier
316 SS Cold Drawn Boiler Tubing Supplier in India

Application Industries for High Quality SS 316 Boiler Tubes

SS 316 Boiler Tubes For Economiser
SS 316H Boiler Tubes For Fire-Tube Boiler
SS 316 Boiler Tubes For Water-Tube Boiler
SS 316H Boiler Tubes For Steam Boilers
SS 316 Boiler Tubes For Air Preheater Unit
SS 316L Boiler Tubes For Petrochemical
SS 316H Boiler Tubes For Cogeneration Facilities
SS 316L Boiler Tubes For Solar Power Industry
SS 316L Boiler Tubes For Electric Power Plants
SS 316 Boiler Tubes For Fossil Fuel Plants
SS 316L Boiler Tubes For Waste Heat Plants
SS 316H Boiler Tubes For Power Generation
SS 316 Boiler Tubes For Commercial Fire and Water Boiler
